DJI AGRAS T70P



Expert in efficiency.

CONTACT

The DJI Agras T70P agricultural drone has recently been updated to support spraying, spreading, and lifting in a variety of operational scenarios, with a maximum payload capacity of 70 kg. It offers greater efficiency and incorporates the Safety System 3.0 and advanced algorithms for comprehensive 24/7 protection.

Key features:

  • 70-liter spray tank, flow rate of 40 L/min;
  • 100-liter distribution tank, flow rate of 400 kg/min;
  • Enhanced display with augmented reality to help avoid obstacles;
  • Maximum operating speed: 20 m/s;
  • 65 kg lift;
  • Ultra-fast charging.

Spraying system: Efficient operation, exceptional performance

The T70P is equipped with a 70-liter tank and dual-atomization centrifugal spray nozzles, which deliver high flow rates for increased flight speed and greater operational efficiency in field applications. Orchard users can opt for an optional mist nozzle kit, which improves both flow rate and atomization, ensuring complete penetration even through dense foliage and tall plants.

Field operations

Increased operational efficiency

20%

High Flow

30L/min

Effective spray width

4-11m

Maximum flight speed

20ms

Garden operations

Four sprinklers

40L/min

Increased penetration and coverage of the underside of the leaves

65%

Water-cooled mist sprayer (optional)

The fine droplets, measuring just 50 μm, penetrate the vegetation effectively, ensuring complete foliar coverage. The new liquid duct design quickly dissipates the heat generated by the two centrifugal motors, improving durability and extending the system’s service life.

Dual atomization centrifugal sprinkler

New flow path design; the dual separators support a maximum flow rate of 30 L/min and a particle size range of 50–500 μm, making them suitable for most operating scenarios.

Magnetically driven impeller pumps

Corrosion-resistant, stable, and reliable, an optimized impeller structure and increased chamber volume meet the high flow demands of orchard environments.

Solenoid Valves

Precise start-up and shutdown eliminate leaks.

Dual-channel electromagnetic flowmeter

Accurate real-time flow detection and dynamic control ensure high-precision operations. It avoids direct contact with the liquid, preventing corrosion and increasing durability.

Propagation system: Exceptional efficiency and performance

The T70P features a new spreader system with increased payload capacity, delivering a 270% increase in spread rate for significantly improved efficiency. Equipped with a new screw feeder, it accommodates a wide range of granules and excels in various applications, including fields, orchards, and aquaculture.

High-capacity storage tank

100L (70 kg)

Ultra-high flow rate

400kg/min

Effective spread width

10m

Particle size range

0,5-10mm

Completely new screw feeder

Spread accuracy doubled, flow rate increased by 270% and granule applicability improved even further.

High-precision weighing sensor

Provides accurate, real-time visualization of the amount of granules, enabling precise use and replenishment and effectively minimizing waste. Automatic flow calibration and cloud-stored operating templates make spreading operations more accurate and convenient.

Centrifugal spreading disc

Ensures uniform distribution across the entire flow range with exceptional results. Features a stainless steel cap for added durability and strength.

Large loading door

Allows for easy and convenient bulk loading.

Extra-large feeder

Suitable for granules such as fertilizers, wheat seeds, granulated fungicides, animal feed, etc.

Recommended dosage: 75-750 kg per hectare.
Recommended particle size: 0.5-10 mm.

Large feeder (optional)

Suitable for granules such as rice seeds, cover crop seeds, etc.

Recommended dose: 75-270 kg per hectare.
Recommended particle size: 4-10 mm.

Medium feeder

Suitable for granules such as rice seeds.

Recommended dose: 22.5-120 kg per hectare.
Recommended particle size: 4-6 mm.

Small feeder (optional)

Suitable for granules such as rapeseed, granular herbicides, grass seeds, granular insecticides, etc.

Recommended dose: 3–22.5 kg per hectare.
Recommended particle size: 0.5–4 mm.

Safety system: Obstacle avoidance, enhanced display with augmented reality

The T70P is equipped with an intelligent obstacle avoidance system and an augmented reality display. Thanks to Safety System 3.0, its radar and vision systems work together with enhanced algorithms to provide comprehensive obstacle detection, enabling smooth navigation and effortless maneuvering on difficult terrain.

Millimeter wave radar

The front radar performs 5,000 vertical scans of the airspace per second, combined with a 360° horizontal mechanical rotation scan, along with a rear radar, providing a wider detection range.



Sistema Tri-Vision

Two black-and-white fisheye cameras and an FPV camera work in conjunction with the radar using visual fusion algorithms to improve terrain tracking and obstacle avoidance capabilities.



Night navigation light

In addition to the existing low-beam headlights, new high-beam headlights and supplemental downward lighting have been added. The downward lighting is automatically activated during landing, ensuring safer nighttime operations.



Color FPV camera with night vision

Using virtual gimbal technology, the tilt angle of the FPV camera can be freely adjusted. It supports night vision mode, and when combined with night navigation lights, obstacles remain clearly visible even in the dark.

Ability to avoid obstacles

It supports 360° avoidance of horizontal and vertical obstacles, as well as terrain tracking on steep slopes without the need for aerial mapping. The detection rate for diagonal cables and power lines has been improved, ensuring clear detection of all obstacles on the ground.

Smart Problem-Solving

The recently updated Safety System 3.0 incorporates intelligent detection algorithms that enable obstacle detection and more precise route selection, significantly improving obstacle clearance rates. In addition, it features an advanced terrain mapping algorithm that accurately captures terrain features for high-precision terrain-following operations in agricultural environments.

Obstacle Type Detection

Thanks to more accurate detection and smarter algorithms, obstacle types can be clearly displayed on the remote control and saved to the flight log with a single click, thereby improving flight safety.

Augmented Reality Safety Assistance

It supports augmented reality visualization of utility poles, vehicles, and obstacles during takeoff and landing, generates augmented reality flight paths during operation, and provides guidance on the flight path. It also includes a safe landing projection to facilitate the return and landing.

Land monitoring without mapping

Navigate mountain slopes with gradients of up to 90° without the need for aerial mapping, thereby meeting the operational needs of most orchards.

Safety locks for arms

It automatically detects whether the arm is locked before operation to ensure operational safety.

Your transportation assistant

The T70P transforms into a transport solution with a lifting capacity of 65 kg, allowing it to carry more cargo and travel longer distances. Features such as automatic balance control, weight detection, and automatic navigation to loading and unloading points make it adaptable to a variety of agricultural transport scenarios.

  • Solar panels;
  • Fruit;
  • Building materials;
  • Shoots.



Automatic balance control

Using a triaxial force sensor, the drone can automatically adjust its attitude during flight to eliminate roll, ensuring safer operations.

Real-time weighing

A triaxial force sensor provides real-time weight monitoring to prevent overloads and ensure operational safety.

Marking loading and unloading points using mobile devices

Operators can use their mobile phones, together with the RTK module, to add loading and unloading points, which are then synchronized with the remote control. Pilots can quickly locate destinations using augmented reality projection on the remote control.
Freely select loading and unloading points and access them with a single click.

Automatic flight

Freely select loading and unloading points and access them with a single click.

Powerful performance, greater efficiency.

The T70P effectively reduces energy consumption by further optimizing the power supply system, while maintaining the same operating area and efficiency.

62-inch carbon fiber propellers

Carbon fiber propellers offer greater rigidity and lower weight, resisting deformation even at high temperatures. With an optimized aerodynamic profile and an increased diameter, efficiency improves by 15%.

Engine optimization

With improvements in the motor’s electromagnetic design and manufacturing processes, efficiency has increased by 3%

Clamp for oscillating propellers

It reduces body vibration by 40%, resulting in a smoother ride and lower fuel consumption.

Easy to control for both beginners and experienced pilots

The DJI RC Plus features a 7-inch high-brightness display that is 16% brighter for clear visibility in sunlight. Battery life—both for the internal and external batteries—has been extended by 30 minutes. New backlit buttons improve nighttime operation, and customizable physical buttons offer flexible control.

Get started easily

Simply complete the on-site planning and operate with a single click, without the need for manual intervention.

Step 1: Simple field planning

Choose from several planning methods. Once the terrain has been mapped, the flight path is generated automatically.

Step 2: Fully automatic operation with a single click.

Easily access parameter templates with a single click for added convenience and speed.

Step 3: Smart Return Home

It automatically returns to its charging station when it runs out of pesticide or when the battery is low.

Improve accuracy and efficiency

Experimenta un manejo manual fluido e intuitivo, combinado con una gama de potentes y eficientes funciones de asistencia. Afronta incluso los terrenos más difíciles con confianza y facilidad.

Operations across multiple sectors

Efficiently plan multiple adjacent parcels at once. Practical features for manual mode

Practical features for manual mode

Streamline operations on small, complex charts with handy tools like one-click chart saving and one-click resumption from breakpoints, ensuring efficient, stress-free workflows.

Free flight paths

Effortlessly adapt to a variety of scenarios, including mixed cropping, intercropping, and rice paddies. Achieve greater operational flexibility for more efficient workflows.

Integrated operations and mapping

Survey up to 17 hectares of large fields or 8 hectares of orchards per flight, with rapid data processing upon landing.

Rigorous testing standards

The T70P has undergone 700 hours of reliability testing, including real-flight aging, accelerated component fatigue testing, and evaluations at extreme temperatures. These tests ensure their stability and reliability, delivering unmatched performance under a variety of conditions.

Impeccable signal stability

The enhanced O4 video streaming algorithm ensures consistent signal availability. The O4 Relay is designed to deliver optimal performance even under challenging signal conditions, ensuring smooth and efficient operation.

Power system

Ultra-fast charging, energy-efficient design

The T70P achieves significant energy savings thanks to its improved energy efficiency, effectively reducing operating costs. It supports two smart flight batteries, adapting to a variety of operational needs.

DB1580 Smart Flight Battery
  • 30 Ah,
  • 1500 ciclos de carga en garantía
  • 500 A high-power connector
  • Weight: 11,7 kg
  • Asa ergonómica
DB2160 Smart Flight Battery
  • 41 Ah
  • 1500 ciclos de carga en garantía
  • 500 A high-power connector
  • Weight: 14,7 kg
  • Asa ergonómica
C10000 Smart Power Supply
  • Single-phase power input
  • 9000 W fast charging
  • Adaptive power protection
  • 1.5-meter charging cable
C12000 Smart Power Supply
  • Three-phase power input
  • 12,000 W fast charging
  • Adaptive power protection
  • 1.8-meter charging cable
D14000iE Multifunctional Inverter Generator
  • 11,500 W fast charging
  • 1500 W AC output
  • 1.8-meter charging cable
